| post date: | dec 24,2021 |
| expiry date: | dec 24,2022 |
| detailed description: |
payment method: t/t model pu530-02-d port size 1/4" ,1/8" (exhaust ports) body material aluminum alloy fluid compressed air acting internal pilot sectional area 14m㎡ operating pressure rang 2-8kgf/c㎡ proof pressure 9.9kgf/c㎡ ambient temperature -10℃-60℃ duty cycle 100% ed protection class ip65(din 40 050) insulation class f voltage tolerance ±10% standard voltage 220vcd,110vcd,24vdc,(the other voltage is optional) net weight 475g |
